Radar's beam pattern aims to provide you with usable driving light, illuminating a wide area while providing a solid hot spot, making it an excellent choice for enhancing nighttime visibility and ideal for medium-range lighting (300-800m).

Each time Radar starts, it displays a light sequence for about one second.

It is compatible with most off-road vehicles (ATVs, UTVs, trucks, SUVs, Jeeps) with flat mounting surfaces. For special models, custom brackets are recommended.

As a general guide, we recommend 7–9" pods near the front bumper for maximum forward illumination. Mounting larger lights lower on the vehicle can also help reduce unwanted glare.

3–5" pods work well on A-pillars, either aimed forward for more balanced coverage or angled outward to illuminate the sides of the trail and ditches.

Smaller flood lights, typically 3" and below, are ideal for side lighting around camp, rock lights, or rear-facing backup and work lights.

The best setup ultimately depends on your vehicle, mounting position, and how you use it.

In many cases, yes.

On a conventional multi-function light, each function is typically controlled by a separate positive wire. For example, a 4-pin light with a main beam, amber DRL, and white DRL may use three pins for those individual functions and one pin for ground. This can allow each function to be connected to a separate channel on a compatible switch panel.

However, some of our more advanced lights, such as the Hornet Series, use an integrated control module to manage multiple functions. Bypassing the supplied wiring harness and connecting these lights directly to a switch panel may cause certain functions to operate incorrectly.

For these products, we recommend using the supplied control system. If you still want an additional master switch, you may be able to control the main power supply through your switch panel instead.

If you're unsure whether a specific HIMA light can be connected directly to your switch panel, contact us before installation and we'll help you check.

For most installations—such as bumpers, roof racks, and existing mounting points—you usually won't need to make major modifications. The light can typically be installed using a secure mounting point on your vehicle together with the supplied bracket.

Some locations may benefit from a vehicle-specific mount. For example, if you're installing lights on the A-pillar of a Jeep Wrangler, we recommend using a dedicated A-pillar bracket for a cleaner and more secure installation.

Wiring requirements depend on your vehicle and where you mount the light. If the switch wiring needs to pass through the firewall, some vehicles may require a small opening to be made in an existing rubber firewall grommet.

If you're not sure about your installation, send us your vehicle model and planned mounting position and we'll be happy to help.

Yes. HIMA lights are designed for demanding outdoor environments and are tested to meet IP68/IP69K dust- and water-resistance standards.

They are suitable for use in rain, snow, mud, dust, and other typical off-road conditions.

If your light suffers water or dust ingress due to a manufacturing defect, please contact us and our support team will assist you.

The easiest way is to compare the real-world beam shots on each product page. They show how each light actually distributes light on the road or trail.

If you prefer to compare specifications, look at the 1 Lux @ Distance figure. A greater distance generally indicates stronger long-range performance.

For wider illumination, pay more attention to the beam pattern and horizontal coverage shown in our beam shots rather than distance alone.

Yes. We offer many replacement parts and accessories separately, including covers, mounting hardware, and selected installation components.

If you can't find the part you need on our website, contact us and we'll help you check availability.

We're here to help.

Email us at support@hima4x4.com, and we typically respond within 24 hours.

You can also send us a message through our official Instagram or Facebook pages. If possible, include your vehicle model, the product you're installing, and a photo of the mounting location so we can better understand your setup.

Yes. We offer a 30-day return and refund policy.

Please contact us within 30 days of receiving your order to request a return or exchange. Shipping fees are non-refundable.

Unfortunately, we are unable to accept return requests after the 30-day return period has ended.
